All 3D design work undertaken by Rubitech Design Services will be created in Autodesk Inventor 2010. Please see below for file formats supported by the software.
Supported non CAD file export formats
Native File Type | Export |
Part (*.ipt) | Design Web Format (*.dwf, *.dwfx) Portable Document File (*.pdf) |
Assembly (*.iam) | Design Web Format (*.dwf, *.dwfx) Portable Document File (*.pdf) |
Drawing (*.idw, *.dwg) | Design Web Format (*.dwf, *.dwfx) Portable Document File (*.pdf) Drawing Exchange Format (*.dxf) |
Presentation (*.ipn) | Design Web Format (*.dwf, *.dwfx) Portable Document File (*.pdf) |
Supported foreign CAD formats and versions
File Type | Import | Export |
Alias (*.wire) | all versions | - |
CATIA V5 (*.CATPart, *.CATProduct) | R6-R18 | R10-R18 |
IGES (*.igs) | all versions | 5.3 |
JT precise (*.jt) | 7.0, 8.0, 8.1, 8.2, 9.0, 9.1 | 7.0, 8.0, 8.1, 8.2, 9.0, 9.1 |
NX (*.prt) | 3-6 | - |
Parasolid (*.x_b, *.x_t) | up to version 20.0 | 9.0-20.0 |
Pro/ENGINEER (*.prt, *.asm) | up to version 4.0 | - |
Pro/ENGINEER Granite (*.g) | up to version 5.0 | 1.0-5.0 |
Pro/ENGINEER Neutral (*.neu) | all versions | all versions |
SAT (*.sat) | 4.0-7.0 | 4.0-7.0 |
SolidWorks (*.prt,*.sldprt,*.sldasm) | 2003-2009 | - |
STEP (*.stp) | AP214, AP203E2 | AP214, AP203E2 |
STL (*.stl) | - | all |
XGL/ZGL (*.xgl/*.zgl) | - | all |
